Parameter Description
0 = set to this value when alarm is triggered
1 = set to this value when alarm is acknowledged.
Action Actions executed when the alarm is triggered. Additional conditions can be specified in the Events
column.
See "Setting events" on page170 for details.
User
Action
Actions executed when user press the action button in the active alarm widget.
See ""Active Alarms widget" on page172 for details.
Description Alarm description. This text supports the multiple language features and can be a combination of static
and dynamic parts, where the dynamic portion includes one or more tag values.
See "Displaying live alarm data" on page178 for details.
Color Foreground and background colors of alarm rows based on the status of alarm.
AckBlink Blinking for triggered alarms. If selected the alarm rows blinks until acknowledged. Only effective if Ack is
selected.
Severity Severity of the alarm. If multiple alarms are triggered simultaneously, actions will be executed based on
severity settings.
0 = not important
1 = low
2 = below normal
3 = normal
4 = above normal
5 = high
6 = critical
Events Conditions in which the alarms are notified, logged or printed.
See "Setting events" on page170 for details.
Remote alarms acknowledge
When the Remote Ack parameter is set, an alarm can be acknowledged from a PLCdevice setting a tag value to a
nonzero value. The acknowledged status is notified to the PLC device by the Ack Notify flag.
Alarms acknowledgement process
Remote Ack tag is set/reset by the PLC to request the acknowledge, and Ack Notify is set/reset by HMI device to notify
the execution of the acknowledge.
168
HMWIN Studio |User Manual|v206 (2017-06-30) |EN|© 2014-2017 Panasonic Electric Works Europe AG
