Adding a report
Path: ProjectView> Config > double-click Reports
In Reports editor, click Graphic Report or Text Report: one new row is added to the table.
Report types
Report
type
Description
Text
Reports
Use for line-by-line printing of alarms.
Only used for line printers.
Text is sent to the printer without using any special driver.
Important: This printing mode requires using a physical port and only works on
Windows CEplatforms.
Graphic
Reports
Contain graphical elements and may include complex widgets such as screenshots or alarms.
Important: Each printer requires a specific printer driver. See "Configuring graphic
reports" on the facing page for a list of supported printer drivers.
Configuring text reports
Use the Reports editor . Paper Size in number of characters.
Setting printer options
Use printer options to control flush of pages on printer.
Printing starts either immediately or after a timeout. In printer options you can force flush as soon as a specific condition
occurs, after a specified number of events, lines or seconds.
Note: Text reports do not support PDF format.
Setting alarms layout
Paper Size is the width of paper in number of characters.
Adding fields to the report
To add an item to the report, drag and drop it on the template page from the Available fields list.
246
HMWIN Studio |User Manual|v206 (2017-06-30) |EN|© 2014-2017 Panasonic Electric Works Europe AG
Adding a report
