17 Trends
Trends allow you to sample and record the values of specified tags according to specific sampling conditions. The trend
function includes trend acquisition and trend display.
Trend acquisition parameters are set in the Trend editor so that data can be stored. Stored data can then be displayed in a
graphical format using a trend widget.
Data logging 190
Exporting trend buffer data 191
Trend widgets 192
History trends 194
Trend widget properties 195
Trend widget gestures 196
Values outside range or invalid 197
Showing trend values 198
Scatter diagram widget 199
HMWIN Studio |User Manual| v206 (2017-06-30) | EN| © 2014-2017 Panasonic Electric Works Europe AG
189
