IP Camera widgets
Path: Widget Gallery> Media> IPCamera
Use these these widgets to show images captured from an IP Camera or a video stream.
Parameter Description
Camera URL URL of the IP Camera when used in JPEG format.
Refresh Rate Number of JPEG images for second allowed. Max rate = 1 fps.
User Name Name of user allowed to access the camera.
Set this parameter when access to the camera is password protected.
Password Password to access the camera.
MJPEG Camera URL URL of MJPEG streaming (for example, http://192.168.0.1/video.cgi)
When this widget is used to stream HTTP MJPEG, Camera URLand Refresh Rate are ignored.
Performance of streaming is not fixed and depends on many factors such as: frame size, frame compression level, CPU of
HMI device, quality of IPCamera. Based on these factors the widget can reach up to 25 fps.
You can add multiple IP Camera widgets, but this will reduce the frame rate for each widget.
Supported IPCameras
The following IP Cameras have been tested so far:
IPCamera Protocol URL
Apexis APM-J901-Z-WS PTZ IP Camera MJPEG
HTTP
http://{ip_address}/videostream.cgi
http://{ip_address}/snapshot.cgi
AXIS M3027-PVE Network Camera MJPEG
HTTP
http://{ip_address}/axis-cgi/mjpg/video.cgi
http://{ip_address}/axis-cgi/jpg/image.cgi
DAHUA DH-IPC-HD2100P-080B 1.3mp
Outdoor Vandalproof
HTTP http://{ip_address}:9988/onvif/media_
service/snapshot
HMWIN Studio |User Manual| v206 (2017-06-30) | EN| © 2014-2017 Panasonic Electric Works Europe AG
295
32 Special widgets
