Configuring the email server
To configure the email server, enter the following information for the EmailConfig setting:
Parameter Description
SMTP Address SMTP server address.
Server Port Port for SMTP server connection (default = 25).
Require Auth Select if the SMTP server requires authentication.
User Name Username for sending mail using SMTP server.
Password Password for sending mails using SMTP server.
Encryption Encryption type (none or SSL).
Click + to add more email servers.
Tip: Use tags if you want change the server parameters dynamically from the HMI Runtime.
Configure emails
Enter the following information for the EmailInfo setting:
Parameter Description
Name Optional, this information is only for the log.
Description Optional, this information is only for the log.
From Optional, sender email address (for example, John@domain.com).
To Recipient e-mail addresses. To enter multiple addresses, separate them with a semi-colon.
Subject Subject of email.
Attachment Path of the file to be sent as attachment. Only one attachment at a time can be sent.
Note: The maximum size of the attachments is usually set by the SMTP server.
Body Main content of the email. Here you can insert live tags if you include them in square
brackets.
For example, a message body as “Tag1 value is [Tag1]”, will be sent as “Tag1 value is 45”, if
the current value of Tag1 is 45.
Tip: Attach a string tag to the From, To and Subject fields so that their value can be changed in the HMI
Runtime.
