SD card variables
Information on the external SD card.
Variable Description Data type
SD Card FreeSpace Available space on card in bytes uint64
read only
SD Card Name Name of SD card string
read only
SD Card Size Size in bytes of the card plugged in the slot uint64
read only
SD Card Status 0 = SD card unplugged
1 = SD card plugged
int
read only
Server variables
Server status.
Important: All variables refer to server, not to HMWIN Client.
Variable Description
Data
type
Current page Name of current page string
Current project Name of current project string
Operating mode
time
Seconds elapsed since device started operating mode uint64
Project load time Date when the project was loaded on the HMI Runtime as in System Date format
(milliseconds).
uint64
Time variables
System time expressed in UTC format.
Variable Description Data type
Day Of Month Range: 1–31 int
Day of Week Range: 0 = Sunday, .. , 6 = Saturday int
86
HMWIN Studio |User Manual|v206 (2017-06-30) |EN|© 2014-2017 Panasonic Electric Works Europe AG
