Tag actions
Interacts with tags.
DataTransfer
Exchanges data between:
l two controllers,
l registers within a controller,
l from system variables to controllers,
l from controllers to system variables
The various tag types include a controller tag, a system variable, a recipe tag and widget property.
ToggleBit
Toggles a bit value of a tag.
BitIndex allows you to select the bit to be toggled: toggling requires a read-modify-write operation; the read value is
inverted and then written back to the tag.
SetBit
Sets the selected bit to “1".
BitIndex allows you to select the bit position inside the tag.
ResetBit
Resets the selected bit to “0”
BitIndex allows you to select the bit position inside the tag.
WriteTag
Writes constant values to the controller memory. Specify tag name and value.
StepTag
Increments or decrements tag value.
Parameter Description
TagName Name of tag to increase/decrease
Step Step value
Do not step over limit Enables step limit
Step Limit Value of step limit, if enabled.
HMWIN Studio |User Manual| v206 (2017-06-30) | EN| © 2014-2017 Panasonic Electric Works Europe AG
143
10 Actions
