Property Description
FreeType Font
Rendering
Switches to FreeType the font rendering used by HMWIN Studio and runtime.
Software plug-in
modules
Defines which software modules are downloaded to the Runtime with the project. See
"Software plug-in modules" on page55
Behavior These properties define different aspects of page behavior. See "Behavior" on page56
Style Combo Box View Mode (see "Combo Box widget" on page286 for details)
l Context
l Full Screen
Developer tools
Collection of runtime debugging functions that can be enabled or disabled.
Enabling developer tools
1. In Properties pane, set Developer Tools to true.
2. Download the project.
3. Open context menu.
4. Select Developer tools.
Developer tool list
Tool Description
Show/Hide
all
Shows a dialog containing information about device status like CPU load, memory usage, event queues.
CPU
statistics
Shows information on CPU load. See "CPU Statistics" on the facing page.
Memory
statistics
Shows information about system RAM . A negative value indicates that free memory is decreasing.
Event
queues
Shows information on event queues (size, maximum achieved size, number of processed events, last and
maximum processing time). Timing statistics are only available for non-UI queue.
Timelog
summary
Show page loading time.
Embed
window
Allows embedding in runtime the scene or leave the developer tool window as a standalone window
(dialog).
Reset
queue
stats
Resets statistical information on event queues.
52
HMWIN Studio |User Manual|v206 (2017-06-30) |EN|© 2014-2017 Panasonic Electric Works Europe AG
Developer tools
