Note: When transferred, system variables are updated with the status of ongoing operations.
System actions
Used to manage system properties.
Restart
Restarts the runtime.
DumpTrend
Stores historical trend data to external drives (USB drive or SD card).
Parameter Description
TrendName Name of historical trend to store
FolderPath Destination folder:
l Internal = \Flash\QTHMI\workspace\Dump
l USB drive = \USBMemory
l SDCard = \Storage Card
l Public Network = \\<hostname or IP>\sharePath
l Private Network = \\<username>:<password>@<hostname or IP>\sharePath
Note: supported formats for external memory are FAT or FAT32 (NTFS format is
not supported).
Note: Private networks are supported only from Linux devices with BSP 1.0.25
and above.
FileFormat Binary = the buffer is dumped in binary format (a .dat file and .inf file). Both these files are
then required to convert data in .csv format by an external utility.
Compatibility CSV = the buffer is dumped to the specified location as a .csv file format
compatible with versions 1.xx
Compact CSV = the buffer is dumped to the specified location as a .csv file using a newer
format
See "Exporting trend buffer data" on page191
DateTimePrefixFileName true = the dumped file will have date and time as prefix to its name (for example D2012_01_
01_T10_10_Trend1.csv)
HMWIN Studio |User Manual| v206 (2017-06-30) | EN| © 2014-2017 Panasonic Electric Works Europe AG
135
10 Actions
