l WebKit (module required by browser widget – if available)
l PDF Reader
l VNC Server
Note: Not all software plug-in modules are compatible with all HMI device platform.
Once enabled, software plug-in become part of the runtime. Use HMWIN Studio to install it using one of the following
procedures:
l install Runtime/update Runtime
l update package
To remove plug-ins from runtime use one of the following functions in System Mode:
l format flash
l restore factory settings
Important: The system cannot detect automatically which software plug-ins are required by the HMI
application, make sure you select them all in the Project Properties.
Behavior
These properties define various elements of page behavior.
Home Page
The first page loaded at run time (after log-in page if security is enabled in project).
When security is enabled, you can specify a different homepage for each groups of users. In this case this setting is
ignored. See "User management and passwords" on page229 for details.
Page Width/Page Height
Defines the default size in pixel of an HMI page. Default is the display resolution of the HMI device model selected when
creating the project.
Display Mode
Defines HMI device orientation.
Project Type
Defines HMIdevice type for the project. According to the model, some project features and properties are automatically
adjusted.
WARNING: Starting from v2, the HMI Runtime will check if the selected project type is matching with
the HMI device model and will advise with a message when the selected type is not matching: “HMI
Type mismatch. Convert project and download again.”
Panel Memory
Size of the available internal panel memory.
56
HMWIN Studio |User Manual|v206 (2017-06-30) |EN|© 2014-2017 Panasonic Electric Works Europe AG
