Panasonic HMWIN - Touch screen variables

Variable Description Data type
Hour Range: 0–23 int
Minute Range: 0–59 int
Month Range: 1–12 int
Second Range: 0–59 int
System Time The same as UTCtime. It can also be set as date/time for this variable. unsignedInt
Year Current Year int
Touch screen variables
Cursor status and position on the touchscreen. These are properties of the active page and can be selected in the Widget
section.
Note: Page size can be different than HMIdevice display size.
Variable Description Java Script
Page
Touch
X
Page
Touch
Y
Cursor position related to page page.primaryTouch.x
page.primaryTouch.y
Screen Cursor position related touchscreen page.primaryTouch.screenX
HMWIN Studio |User Manual| v206 (2017-06-30) | EN| © 2014-2017 Panasonic Electric Works Europe AG
87
8 System Variables (Attach To)
