Recurring scheduler parameters
Parameter Description
Type Frequency of the scheduled actions
Mode Specific settings required by each scheduler type
Condition Boolean tag (true/false) to activate the specified actions at the moment the timer is triggered. Actions will
be executed if tag = true. By default, actions are executed when the timer is triggered.
Note: Only tags attached to the Boolean data type are shown.
Actions Actions to be executed by the schedule.
Important: Actions and schedule parameters cannot be modified at run time
Date Date when the scheduled actions will be executed
Time/Offset This field display one of the following:
Time = when the scheduled actions will be executed
Offset= delay or advance with respect to the selected mode.
Location Reference location to calculate sunset/sunrise time.
weekdays Days of the week in which the scheduled actions will be executed.
On startup Executes schedule at start up
Enable
schedule
Enables/disables the schedule
Execute
only at
startup
Executes the schedule only once at start up
Schedule type options
Option Description
By Date Actions are executed on the specified date and time.
Daily Actions are executed daily at the specified time.
Every Actions are executed with the specified interval (Range: 1 s–1 day)
Hourly Actions are executed every hour at the specified minute.
Monthly Actions are executed every month at the specified date and time.
