Widget Buttons
Button Description
Open Load text file inside the TextEditor
Save Save text file
Cancel Remove all changes from last OPEN or SAVE command
Edit Enter in edit mode
Insert Insert a new line
Delete Delete current line
Up/Down Move cursor up/down
Widget Properties
Option Description
Keyboard TextEditor widget has an embedded keyboard. When widget is used without the embedded
keyboard, the alphabetic keyboard will be displayed when enter edit mode.
l Hidden
l Visible
FTP Config FTP parameters to download the text file from a remote FTP server. Leave this filed empty
to load the text file from the local HMI device.
Parameter Description
FTP Address FTP server IP Address
Server Port Port for FTP connection (default = 21).
Authentication Select the FTP authentication to use:
l Normal (Username and password required)
l Anonymous
User Name Username of the remote FTP account
Password Password of the remote FTP account
File Name File name to edit. When empty a file browser to load a local file will be opened
Syntax Highlight Type Displays text in different colors according to the selected language
l None
l GCode
HMWIN Studio |User Manual| v206 (2017-06-30) | EN| © 2014-2017 Panasonic Electric Works Europe AG
315
32 Special widgets
