Category Supported features Limitations
l Trend/Graph (RefreshTrend, ScrollLeftTrend, ScrollRightTRend,
PageLeftTrend, PageRightTrend, ScrollUpTrend, ScrollDownTrend,
PageUpTrend, PageDownTrend, PageDurationTrend, ZoomInTrend,
ZoomOutTrend, ZoomResetTrend, ZoomInAxisTrend,
ZoomOutAxisTrend, ZoomResetXAxisTrend, PauseTrend,
ResumeTrend, ShowTrendCursor, ScrollTrendCursor,
ScrollTrendToTime)
l Alarm (ResetAlarm, AckAlarm, SelectAllAlarms, EnableAlarms)
l System (DumpTrend, DeleteTrend, DeleteEventArchive)
l Recipes (DownLoadRecipe, UpLoadRecipe,
WriteCurrentRecipeSet, DownLoadCurRecipe, UpLoadCurRecipe,
ResetRecipe, DumpRecipeData, RestoreRecipeData,
AddRecipeDataSet, DelRecipeDataSet)
l Page actions are
not supported in
alarm trigger
condition
XForms l Scaling
l Offset
l ColorPalette
l BitIndex
l Some parameters
do not support the
ColorPalette
functionality.
Keypads l Only numeric keypads widgets are supported. l Custom keypads
are not supported.
The numeric
keyboard will be
displayed as
numeric widgets
with a read/write or
write mode.
Dialog Page l Supported, you can show them and close them based on the
ShowDialog and CloseDialog actions.
l Dialog pages
support only modal
dialogs.
User
Management
l The login mechanism verifies user credentials on the server. The
user name and password are based on the user credentials defined in
User Management.
l Individual security
settings applied to
widgets or pages
are not supported.
Concurrent
User
Connections
l The web server in the HMI device supports three concurrent
connections at a time.
l If more than 3
connections are
attempted from
remote browsers,
only the first 3
connections will be
permitted.
Working with keypads in HM4Web
The user can click on the Numeric widget and a text box will be displayed in which the new value can be inserted.
