Port Usage
Remote
Access
Board
Management
Runtime/Project
Management
998/udp UDP broadcast (Device
discovery)
- Optional Optional
999/udp UDP broadcast
(Device discovery)
- Optional Optional
5900/tcp VNC Server VNC only - -
5100/tcp JS Remote Debugger - - Optional
1200/tcp CODESYS 2.3 - - -
Remote access
Remote access is required to connect to HMI Runtime using:
l HMWIN Client
l Web access HM4Web
Runtime and project management ports
You use these ports to connect to HMI Runtime for operations such as update, installation and project download.
Board management ports
You use these ports to connect to the HMI device for Board operationssuch as BSP update, splash image download and
so on.
Note: When broadcast service is not available, for example in VPN networks, type in the exact IP address to
connect to the HMI device from HMWIN Studio.
