Parameter Description
Bottom margin
Min height
Max heighty
Min/Max height that widget can assume when the cell is stretched
Stretch Defines the relationship between the heights of the rows that will
be maintained if the grid is stretched
Style parameters
Parameter Description
Left stroke width
Right stroke width
Top stroke width
Bottom stroke width
Strokes width
Left stroke color
Right stroke color
Top stroke color
Bottom stroke color
Strokes color
Background color Row background color
The list of values that are separated by a comma, are related to rows and columns. Example, the first value is for
row 0, the second value for row 1, and so on.
Color format could be #rrggbb or #rrggbbaa, where "aa" is the alpha value which defines the opacity of the color.
Selection parameters
The selection parameters is available only when the grid is used inside a Table Widget (see "Table widget" on page307 for
details)
Parameter Description
Forground color
Background color
Stroke color
Colors that the row assume when it is selected
The list of colors is related with row templates. First color is for row
template 0, second color is for row template 1, and so on.
Cells Properties
Properties of a single cell are available inside the properties panel when a cell is selected. To select a cell: first double click
the widget group, then click the cell to select.
