PageRequest attached to tag "A"
CurrentPage attached to a tag "B" as read/write
SyncOptions remote
Set value of tag "A" to display the requested page on HMI and HMWIN Client. Tag "B" will contain the number of page
currently shown by HMWIN Client.
Example: forced page change from controller/PLC to HMI device and HMWIN Client. Force HMWIN
Client page synchronization with HMI device (not vice versa).
Set properties as follows:
PageRequest attached to a tag "A" as Read/Write
CurrentPage attached to the same tag "A" as per PageRequest
SyncOptions local
Set value of tag "A" to display the requested page on HMI and HMWIN Client. Change page on HMI to display the same
page on HMWIN Client.
Example: forced page change from controller/PLC to HMI device and HMWIN Client. Force HMI page
synchronization with HMWIN Client (not vice-versa).
Set properties as follows:
PageRequest attached to a tag "A" as read/write
CurrentPage attached to the same tag "A" as per PageRequest
SyncOptions remote
Change value of tag "A" to display the requested page on HMI and HMWIN Client. Change page on HMWIN Client to
display the same page on HMI.
Example: synchronize displayed page between HMI device and on HMWIN Client
Set properties as follows:
PageRequest attached to a tag "A" as read/write
CurrentPage attached to the same tag "A" as per PageRequest
SyncOptions local+remote
Changing page on HMI device, same page will be shown on HMWIN Client and vice-versa.
WebPageRequest
You can synchronize pages shown on the HM4Web Clients from a controller such as a PLC.
The following properties can be customized:
58
HMWIN Studio |User Manual|v206 (2017-06-30) |EN|© 2014-2017 Panasonic Electric Works Europe AG
Behavior
