Element Description
Buzzer Variables
Variable Name Description Data Type
Buzzer Setup 0 = disabled
1 = enabled (buzzer sounds as audible on any
touchscreen event)
2 = buzzer status controlled by Buzzer Control
system variable or by Buzzer on Touch property
inside the "Project properties" of main manual
Buzzer on touchscreen (Setup=1)
is not available on Linux
platforms. See "Buzzer on Touch"
property in alternative.
int
Buzzer Control 0 = buzzer off
1 = buzzer on
2 = buzzer blink
int
Buzzer Off Time Duration in milliseconds of off time when blink
has been selected. Default = 1000. Range:
100–5000
int
Buzzer On Time Duration in milliseconds of on time when blink
has been selected. Default = 1000. Range:
100–5000
int
HMWIN Studio |User Manual| v206 (2017-06-30) | EN| © 2014-2017 Panasonic Electric Works Europe AG
95
9 System Variables (Protocol)
