5-26 BRAKES
BRAKE CALIPER ASSEMBLY REPAIR
Removal
1) Remove the wheel (see 3F-4).
2) Remove brake caliper (see 5-25).
Repair
Disassembly
1) Place a rag cushion in front of the pistons to avoid they get
damaged.
2) Remove pistons using compressed air at moderate pressure.
NOTE:
Do not put your hands where pistons could damage
them when coming out suddenly.
3) Remove dust cover.
4) Remove oil-seals (1) from pistons, using a thin blade like a
thickness gauge and paying attention no to damage the
cylinders.
1
