6A-44 ENGINE REPAIR
4) Install pressure plate assembly and clutch disc (see 7C-10).
5) Install gear box assembly (see 7A-9).
6) Go on with installation, noting to tighten at specified torque.
7) Check sensor clearance (9). To adjust it act on bolts (10)
and bracket (11).
Clearance between sensor and flywheel face:
0,8 ÷ 1,5 mm
3) Install bearing plate (3) with bolts (4) and tighten to specified
torque.
Tightening torque bearing plate bolts:
1,8 ÷ 2,8 kg-m (18 ÷ 28 Nm)
3
4
9
10
11
