7A-18 MANUAL TRANSMISSION
28) Remove fixing elements which join retaining plate (36) to
the housing.
29) Remove the retaining plate.
36
Reverse speed gear intermediate control lever
removal.
30) Unscrew the lever pivoting screw (37) and remove the lever
and runner.
37
Removal clutch case and clutch release front cover.
31) Remove screw and washer (38).
32) Remove retaining clip (39)
33) Remove control lever (40) with the pushing bush (41) and
remove lever support pivot.
38
39
40
41
34) Remove fixing elements which join the clutch case to the
gear box housing.
