MANUAL TRANSMISSION 7A-19
35) Remove fixing elements which join front cover (42) to gear
box housing.
36) Remove front cover (42), supplementary washers (43) and
fixed set front bearing.
Removal gear box casing
37) Remove fixing elements which join the two halves of the
gear box housing.
38) Separate both halves using a plastic headed hammer.
CAUTION:
To crack open the two half-casings, hit the ribs using
a plastic hammer.
39) Once two halves are separated, take out the fixed gear set
(45) and the main shaft assembly (46) together with the
primary shaft (47)
45
46
47
42
44
43
42
