7A-20 MANUAL TRANSMISSION
40) Remove the shaft (48) from the reverse speed moveable geari,
using tool (B) ref. 262772
41) If reverse gear intermediate lever (51) has not been removed
and it needs to be, remove it together with the soft runner; it
is not necessary to remove the pivoting screw (52)
48
B
51
52
42) Remove reverse gear (49) and its fitting washer.
49
50
Removal main shaft
43) Separate primary shaft (47) from main shaft (46) without
misplacing synchro cone (53) or needle roller bearing (54)
44) Remove synchro cone (53) which will be loose and needle
roller bearing (54).
54
53
47
46
By the front
45) Remove clip (55)
46) Remove fitting washer (56)
55
56
52
