Connecting automatic dialler (associated dial
A31003-K16-X001-3-7620, 07/99
Hicom 100 E Version 2.1, Service manual
5-19
Installation
5.14 Connecting automatic dialler (associated dial)
An automatic dialler can be connected to an S
0
bus or an a/b terminal for each system (optiset)
telephone, see Section 5.9.
Since it uses the same dialling method as its master telephone, the automatic dialler must be
set accordingly, i.e. with or without automatic line seizure.
Before dialling the destination number, the automatic dialler must first dial
✱
or, in the case of
DP, the substitute code 75, followed by
67
and the internal number of the master telephone (12
in this example). This is followed by the destination number with route code (in the example, 0
as route code).
Example: extension number is 0897220 for extension 12:
The automatic dialler with DTMF and optiset (ENB) must dial the following number:
✱
67 12 0 0897220
The automatic dialler with DP and S
0
must dial the following number:
75 67 12 0 0897220
The length of the entire dialling string should not exceed 16 positions.
5.15 Connecting the fax DDI module
The correct installation sequence must be strictly adhered to when connecting the fax DDI
module or the fax/DDI option may not function properly.
Installation:
1. Remove mains plug from socket > release PSU/UPS screw connections and remove.
2. Plug in fax DDI module.
3. Connect the module’s a/b terminals (AT/BT) to the analogue a/b port of the MB (e.g. ext.
23); analogue access is not identical to fax destination!
4. Insert W1-W2 link.
5. Plug in/screw PSU/UPS and connect to power supply.
See Programming guide, Section 10.8.3 for details on programming.
Very few modems and
no
ISDN cards can dial
*
.
