Function expansions with options bus
Overview of modules
A31003-K16-X001-3-7620
,
07/99
3-24
Hicom 100 E Version 2.1, Service manual
Port Contact Signal Function
X3
1 K 4.21 Flip-flop K4.2 IN
2 K 4.22 Flip-flop K4.2 on
3 K 4.23 Flip-flop K4.2 off
4 K 3.21 Flip-flop K3.2 IN
5 K 3.22 Flip-flop K3.2 on
6 K 3.23 Flip-flop K3.2 off
7 K 2.21 Flip-flop K2.2 IN
8 K 2.22 Flip-flop K2.2 on
X4
1 K 2.23 Flip-flop K2.2 off
2 K 1.21 Flip-flop K1.2 IN
3 K 1.22 Flip-flop K1.2 on
4 K 1.23 Flip-flop K1.2 off
5 +12VI +12V control voltage, optocoupler
6 OPTKP 2 Control input, optocoupler 2
7 +12VI +12V control voltage, optocoupler
8 OPTKP 1 Control input, optocoupler 1
X5
1 K 3.12 Flip-flop K3.1 on
2 K 3.13 Flip-flop K3.1 off
3 K 2.11 Flip-flop K2.1 IN
4 K 2.12 Flip-flop K2.1 on
5 K 2.13 Flip-flop K2.1 off
6 K 1.11 Flip-flop K1.1 IN
7 K 1.12 Flip-flop K1.1 on
8 K 1.13 Flip-flop K1.1 off
X6
1 OPTKP 3 Control input, optocoupler 3
2 +12VI +12V control voltage, optocoupler
3 OPTKP 4 Control input, optocoupler 4
4 +12VI +12V control voltage, optocoupler
5 K 4.11 Flip-flop K4.1 IN
6 K 4.12 Flip-flop K4.1 on
7 K 4.13 Flip-flop K4.1 off
8 K 3.11 Flip-flop K3.1 IN
Table 3-21 Contact assignment of STRB module
