System setting
A31003-K16-X001-3-7620, 07/99
Hicom 100 E Version 2.1, Service manual
10-67
Programming guide
10.7.13.5 Trunk code of main PBX
If Hicom 100E is configured as the satellite station in a network, the trunk code of the main PBX
is to be entered as a "secondary trunk code" for the route containing the lines to the main PBX.
Only then is toll restriction implemented in this route.
Example
: route 2 lines are networked with a main PBX. The trunk code of the main PBX is "8".
D<OK>
Confirm input Route 1, item 1: 9
E
# Select route Route
F
2 Enter route 2 Route 2, item 1: 84
G
* Change input Route 2, item 1:
H
2 Select route code "2" Route 2, item 1: 2
J
<OK> Confirm input Route 2, item 1: 2
K
+ Scroll to item 2 Route 2, item 2: –
L
* Change input Route 2, item 2:
M
3 Select route code "3" Route 2, item 2: 3
N
<OK> Confirm input Route 2, item 2: 3
O
<F8> Return to Start menu System administration
Input sequence Meaning Display
A2 2 3
Secondary trunk code
(select route 1–4 with "+" and "–" or
directly with "#")
Route 1: –
B
+ Scroll to route 2 Route 2: –
C*
Change input Route 2:
D8
Select secondary trunk code Route 2: 8
E<OK>
Confirm input Route 2: 8
F
<F8> Return to Start menu System administration
The secondary trunk code can be deleted by pressing the F3 key under point D.
Input sequence Meaning Display
A route code can be deleted by pressing the F3 key under point C, H or M.
