Station attribute
s
A31003-K16-X001-3-7620, 07/99
Hicom 100 E Version 2.1, Service manual
10-37
Programming guide
10.5.4.14 Normal extensions
The normal extensions are assigned to one of the 4 (up to SW 2.0.1+) or 15 (as of SW 2.0.2)
possible night reference extensions and thus have the same trunk access at night as these
reference extensions.
Example
: ext. 13 and 14 should correspond to reference extension 11 and ext. 12 is the only
extension with unrestricted trunk access at night, see also Section 10.5.4.13.
10.5.4.15 Trunk access with active code lock (as of SW version 2.0.2)
Trunk access for extensions with active code locks can be set for the entire system as of SW
version 2.0.2. The classes of service correspond to the values specified in the chapter "Classes
of service as of SW 2.0.2", see Section 10.5.4.2.
Input sequence Meaning Display
A1 4 2
Trunk access at night for ext. 11 on line
1
(select ext. 11–74 directly with "#",
lines 1–32 by scrolling with "+" and "–
")
Ext. 11, line 1: outward
restricted
B#
Select extension Ext.:
C13
Enter extension 13 Ext.: 13
D<OK>
Confirm input Ext. 13: as for ext. 12
E*
Change input Change for ext. 13:
F
1 Select reference ext. Ref. for ext. 13:
G
11 Enter reference ext. Ref. for ext. 13: 11
H
* Confirm input Ext. 13: as for ext. 11
J
# Select extension Ext.:
K
14 Enter extension 14 Ext.: 14
L
<OK> Confirm input Ext. 14: as for ext. 12
M
* Change input Change for ext. 14:
N
1 Select reference ext. Ref. for ext. 14:
O
11 Enter reference ext. Ref. for ext. 14: 11
P
<OK> Confirm input Ext. 14: as for ext. 11
R
<F8> Return to Start menu System administration
The class-of-service assignment can be changed by entering another reference extension
under point G or O.
