Hicom 100 E Version 2.1, Service manual
2-5
System data
The MDF (main distribution frame) (see Section 3.9) expands automatically with the system,
since each expansion provides the necessary interfaces. Any space that may be required for
future function expansions must be taken into account in the initial plans.
2.5 Hicom 108 system overview
Figure 2-2 Hicom 108 structural concept
Slot 1 for system expansions
:
Analogue (TLA2) or S
0
(STLS2) trunk module (see Table 3-12)
1
Cover/MDF
PSU1Basic system
Function expansions
Hicom 108
1 ... 4
Plug in and
secure (screw)
Plug in
System expansion
