Connecting ISDN terminals
Installation
A31003-K16-X001-3-7620
,
07/99
5-10
Hicom 100 E Version 2.1, Service manual
S
0
bus with Mini-Western socket
Connect S
0
1 through S
0
4, see Figure 5-6
Plug the ISDN terminal (connecting cable) into the Mini-Western socket. A backup supply
(e.g. from Sedlbauer) is required for connecting an ISDN telephone.
Figure 5-5 Examples of Mini-Western socket wiring
Pin assignments
Mini-Western sockets:
8-pole
68741352
SX2SR1SR2SX1
64 1352
SX2SR1SR2SX1
6-pole
3241
SX2SR1SR2SX1
4-pole
Mini-Western cables are always centred relative to their plug terminals when connected
