Siemens Hicom 112 User Manual

Station attribute
s
A31003-K16-X001-3-7620, 07/99
Hicom 100 E Version 2.1, Service manual
10-25
Programming guide
Example
: ext. 26 is to be set up as the entrance telephone.
10.5.2.2 Setting up the entrance telephones (as of SW version 2.0.2)
An entrance telephone can be connected to each free a/b extension port (max. 4). The number
of the entrance telephone extension is programmed for each door (1 to 4).
The entrance telephone must be connected via a door opener adapter if the receiving extension
for the doorbell and the door opener features are to be used.
Example: ext. 25 is programmed as entrance telephone 1, ext. 26 is programmed as entrance
telephone 2
Input sequence Meaning Display
A2 3 1
Entrance telephone Ext. no: –
B*
Change input Ext. no.
C26
26 is to be set up as entrance tel. Ext. no.: 26
D<OK>
Confirm input Ext. no.: 26
E
<F8> Return to Start menu System administration
An existing entrance telephone can be deactivated by pressing the F3 key under point C.
Input sequence Meaning Display
A2 3 1
Entrance telephone 1
(select door 1–4 with "+" and "–" or
directly with "#")
Door 1: –
B+
Change input Door 1:
C25
Ext. 25 is entrance telephone 1 Door 1: 25
D<OK>
Confirm input Door 1: 25
E+
Scroll to entrance telephone 2 Door 2: –
F
* Change input Door 2:
G
26 Ext. 26 is entrance telephone 2 Door 2: 26
H
<OK> Confirm input Door 2: 26
J
<F8> Return to Start menu System administration
An existing entrance telephone can be cancelled by pressing the F3 key under points C and G.
