System settings
Programming guide
A31003-K16-X001-3-7620
,
07/99
10-60
Hicom 100 E Version 2.1, Service manual
10.7.4.4 V.24 port for customer data printout
The customer data printout is assigned to V.24 port 1 (MB) by default.
Example
: assigning the customer data printout to V.24 port 4 (3rd SIB module)
10.7.4.5 V.24 port for call information
The transmission of activated call information data records is assigned to V.24 port 1 (MB) by
default.
Example
: assigning call information to V.24 port 2 (1st SIB module)
Input sequence Meaning Display
A 2 1 3 2 4(up to SW 2.0.2)
2 1 13 24 (as of SW 2.1)
V.24 port for customer data memory Port: 1
B*
Change input Port:
C4
Select port 4 Port: 4
D<OK>
Confirm input Port: 4
E
<F8> Return to Start menu System administration
The customer data printout can be assigned to the appropriate port number by entering a
number from 1 to 5 under point C.
Input sequence Meaning Display
A 2 1 3 2 5 (up to SW 2.0.2)
2 1 13 25 (as of SW 2.1)
V.24 port for call information Port: 1
B*
Change input Port:
C2
Select port 2 Port: 2
D<OK>
Confirm input Port: 2
E
<F8> Return to Start menu System administration
The call information data can be assigned to the appropriate port number by entering a number
from 1 to 5 under point C.
