System setting
A31003-K16-X001-3-7620, 07/99
Hicom 100 E Version 2.1, Service manual
10-59
Programming guide
10.7.4.2 V.24 port for call charges/extension
The call charges/ext. printout is assigned to V.24 port 1 (MB) by default.
Example
: assigning the call charges/ext. printout to V.24 port 3 (2nd SIB module)
10.7.4.3 V.24 port for call charges/line
The call charges/line printout is assigned to V.24 port 1 (MB) by default.
Example
: assigning the call charges/line printout to V.24 port 4 (3rd SIB module)
Input sequence Meaning Display
A 2 1 3 2 2 (up to SW 2.0.2)
2 1 13 22 (as of SW 2.1)
V.24 port for call charges/ext. Port: 1
B*
Change input Port:
C3
Select port 3 Port: 3
D<OK>
Confirm input Port: 3
E
<F8> Return to Start menu System administration
The call charges/ext. printout can be assigned to the appropriate port number by entering a
number from 1 to 5 under point C.
Input sequence Meaning Display
A 2 1 3 2 3 (up to SW 2.0.2)
2 1 13 23 (as of SW 2.1)
V.24 port for call charges/line Port: 1
B*
Change input Port:
C4
Selecting port 4 Port: 4
D<OK>
Confirm input Port: 4
E
<F8> Return to Start menu System administration
The call charges/line printout can be assigned to the appropriate port number by entering a
number from 1 to 5 under point C.
