System data
Euroset line 36/Hicom 118-2
A31003-K16-X001-3-7620
,
07/99
12-12
Hicom 100 E Version 2.1, Service manual
12.3 Euroset line 36/Hicom 118-2 module overview
Expansion modules, option modules and cables, plug connectors and national codes,
see Section 3.1.
12.3.1 Euroset line 36 motherboard
The MB 4/4 motherboard is the main board and accommodates 4 digital extension interfaces
(U
P0/E
), 4 analogue extension interfaces (a/b), the V.24 interface (SIC - serial interface cable),
the signalling unit (SIU), a real-time clock (NC battery only in SW 2.0.2) and a PCM highway
controller and conference circuit.
Euroset line 36 MB 4/4 - motherboard with 4 x U
P0/E
, 4 x a/b
Module Item code number Remarks
MB 4/4 S30817-Q920-G601 Euroset line 36
MB 6/4 S30817-Q920-K701 Hicom 118-2
EB 118-2 S30817-Q952-A601 Expansion module for Hicom 118-2
Connecting cable C39195-Z7001-C45 MB <-> EB
PSU 3 S30122-K5449-A312 With intermediate ring
PSU 2 S30122-K5449-X312
UPS 3 S30122-K5451-A312 With intermediate ring
UPS 2 S30122-K5451-X312
Table 12-5 Overview of item code numbers
El 36 Ext. no. Int. ext.
no.
DDI no. Port
numbering
Type
MB
U
P0/E
11 11 11 1 U
P0/E
MU
P0/E
master
12 12 12 2 U
P0/E
M
13 13 13 3 U
P0/E
M
14 14 14 4 U
P0/E
M
17 17 17 1 U
P0/E
S U
P0/E
slave
18 18 18 2 U
P0/E
S
19 19 19 3 U
P0/E
S
20 20 20 4 U
P0/E
S
a/b
23 23 23 1 a/b
24 24 24 2 a/b
25 25 25 3 a/b
26 26 26 4 a/b
Table 12-6 Standard numbering, MB 4/4 Euroset line 36
