Networking
Programming guide
A31003-K16-X001-3-7620
,
07/99
10-14
Hicom 100 E Version 2.1, Service manual
The digits "2" and "3" are then entered as route codes for route 2 (see "Route codes" Section
10.7.13.4).
Now activate digit repetition for route 2, see Figure 6-8
.
All Hicom 100E extensions can now reach the main PBX extensions simply by dialling the
appropriate 3-digit number (e.g. 256 or 402).
10.3.9 Route seizure
Linear route seizure (default)
can be changed to cyclical route seizure for each route.
Example
: lines in route 1 are to be seized in a cyclical manner.
Input sequence Meaning Display
A 1 6 6 (up to
SW2.0.2)
1 6 16 (as of SW 2.1)
Digit repetition for route 1
(select route 1–4 with "+" and "–" or
directly with "#")
Route 1: off
B+
Digit repetition for route 2 Route 2: off
C*
Change input Route 2:
D1
Digit repetition ON Route 2: on
E<OK>
Confirm input Route 2: on
F
<F8> Return to Start menu System administration
Activated digit repetition can be deactivated by entering "0" under point D.
Input sequence Meaning Display
A 1 6 7 (up to
SW2.0.2)
1 6 17 (as of SW 2.1)
Route seizure for route 1
(select route 1–4 with "+" and "–" or
directly with "#")
Route 1: linear
B*
Change input Route 1:
C0
Cyclical seizure Route 1: cyclical
D<OK>
Confirm input Route 1: cyclical
E<F8>
Return to Start menu System administration
Seizure can be changed from cyclical to linear by entering "1" under point C.
