Add-on modules for system expansion
A31003-K16-X001-3-7620, 07/99
Hicom 100 E Version 2.1, Service manual
3-13
Overview of modules
3.5 Add-on modules for system expansions
The Hicom 108 has one slot for the TLA2 (analogue trunk) or STLS2 (S
o
) module.
The Hicom 112 has two slots (1 and 3) for system expansions.
The Hicom 118 has 4 slots for expanded system configurations. The modules can be inserted
in any of these slots. Refer to the relevant module descriptions for details of any restrictions.
Subsequent expansions carried out on the Hicom 118 should be installed following the new
equipping sequence for extension and trunk modules.
If slot 1 is assigned with an SLU8 (U
P0/E
extension) or an SLAS16 (a/b extensions), slot 2 is
deactivated.
The above table only shows the possible slots. It does not illustrate the maximum configuration
possible or authorization-related restrictions.
11 a6 - port 6
12 b6 - port 6
Module Hicom 108 Hicom 108
NDL
Hicom 112 Hicom 118 Hicom 118-2*
slot
SLAS16 -- -- 1, 3 3, 4 3, 4, 6, 7, 8
SLAS8 -- 3 -- 1 - 4 1 - 8
SLAS4 -- -- -- 1 - 4 1 - 8
SLU8 -- -- -- 3, 4 3, 4
STLS4 -- -- 1, 3 1 - 4 1, 2, 3, 4
STLS2 1 -- 1, 3 1 - 4 1, 2, 3, 4
TLA8 -- -- 1, 3 1 - 4 1 - 8
TLA4 -- 1 1, 3 1 - 4 1 - 8
TLA2 1 1 1, 3 1 - 4 1 - 8
*= see Section 12.3.2
Table 3-12 Add-on modules for system expansions
Only SLAS8 modules can be inserted in slots 1 and 2. SLU modules must not be
inserted in slot 1.
Contact Port X1 Port X2 Port X3 Port X4
Table 3-11 Contact assignment of the MB interfaces 6/4 Hicom 118
