System data
Euroset line 36/Hicom 118-2
A31003-K16-X001-3-7620
,
07/99
12-10
Hicom 100 E Version 2.1, Service manual
12.2.9 Technical data
Dimensions and interfaces as for Hicom 100 E
, see Figure 2-5 and Table 2-3.
System Width Height Depth
Euroset line 36 (2.0.1+) basic configuration 470 370 140
Euroset line 36 (2.0.1+) with max. expansions 470 630 140
Euroset line 36 (2.0.2) basic configuration 470 370 110
Euroset line 36 (2.0.2) with max. expansions 470 630 110
Hicom 118-2 basic box basic configuration 470 370 110
Hicom 118-2 basic box with max. expansions 470 630 110
Hicom 118-2 expansion box 470 370 110
Table 12-2 System dimensions in mm
Operation Transport Storage
Ambient temperature in °C +5 to +40 -40 to +70 -5 to +45
Relative humidity in % 85 95 95
Table 12-3 Climatic conditions
Caution
Do not expose to direct sunlight and keep appliance away from heaters to avoid the
danger of localised overheating.
f condensation forms, allow the appliance to dry before operation. It is essential to
ensure that condensation cannot form while the appliance is in operation.
!
