Dial-in procedure (previously T-Net) as of V2.1
Least Cost Routing (LCR)
A31003-K16-X001-3-7620
,
07/99
8-8
Hicom 100 E Version 2.1, Service manual
Entries 1-10 and 11 (local network) are mandatory!
Entries 12-50 must be made for each user.
Codes Meaning
27
Select least cost routing
27 1
Routing on/off: ON
27 3
Routing type: set to DICS
27 4
Access code: enter number of DICS server
27 5
Authorization code: to be entered personally
27 6
Exception table: Table 8-6
Table 8-5 Configuration example for DICS
Entry
no.
Entry Entry
no.
Entry Entry
no.
Entry Entry
no.
Entry Entry
no.
Entry
1111 *213141
2 2 12 ** 22 32 42
3 3 13 23 33 43
4 4 14 24 34 44
5 5 15 25 35 45
6 6 16 26 36 46
7 7 17 27 37 47
8 8 18 28 38 48
9 9 19 29 39 49
10 01 20 30 40 50
* Entry no. 11: Own local network
** Entry no. 12-50: Additional area codes locally
Table 8-6 Exception table for DICS
