System data
Euroset line 36/Hicom 118-2
A31003-K16-X001-3-7620
,
07/99
12-4
Hicom 100 E Version 2.1, Service manual
12.2.2 System types
The systems are available in the following basic configurations:
Euroset line 36
with 4 or 6 slots, 4 U
P0/E
and 4 a/b extension interfaces.
Hicom 118-2
(basic box) with 4 slots, 6 U
P0/E
and 4 a/b extension interfaces.
A distinction is made between the following components:
●
Basic system, motherboard with V.24 interface via mini-DIN plug.
●
Expansion box (Hicom 118-2 only) EB expansion board.
●
PSU3 power supply unit for esl 36 (SW 2.0.1+) with intermediate ring.
UPS3 uninterruptible power supply for esl 36 (SW 2.0.1+) with intermediate ring.
PSU2 power supply unit for esl 36 (SW 2.0.2)/Hicom 118-2.
UPS2 uninterruptible power supply for esl 36 (SW 2.0.2)/Hicom 118-2.
●
Expansion cards for Euroset line 36:
The modular design means that the slots can be more or less freely assigned in accor-
dance with requirements.
SLAS subscriber line analogue with 4, 8 or 16 a/b interfaces (subscriber line module).
TLA trunk line analogue with 2, 4 or 8 analogue trunk interfaces (line module).
●
Expansion modules for Euroset line 36:
ALUM trunk failure transfer with 4 transfer options for analogue lines
Fax/DDI with announcement (DTMF)
GEE call-charge pulse recognition for 4 analogue trunk interfaces
SIB serial interface board (optional V.24 interface)
STRB control relay module with 4 control inputs and 4 control outputs
●
Expansion cards and expansion modules for Hicom 118-2 (basic box) see Section 3.5 and
Section 3.6
12.2.3 Main distribution frame
The MDF (main distribution frame) expands automatically with the system, since each expan-
sion provides the necessary interfaces. Any space that may be required for future function ex-
pansions or an expansion box (Hicom 118-2) must be taken into account in the initial plans.
