A31003-K16-X001-3-7620, 07/99
Hicom 100 E Version 2.1, Service manual
11-21
Plus products
●
Line feed : number of linefeeds at the start and end of a page. Single page feed: enter * to
end line feed.
●
Automatic query: query the feature statuses, e.g. all occupied rooms.
●
Default language: currently only German.
●
Acoustic alarm: an alerting tone is output (e.g. guest cannot be woken up).
●
Hotel data: hotel name and address for invoices. Maximum four lines with 24 digits each.
11.5 Multiplexers
Within the framework of system networking (branch concept), multiplexers are used to com-
press calls via a dedicated line from a master PBX (e.g. Hicom 300) to a slave PBX (Hicom 100
E). For more information, please refer to the appropriate manufacturer specifications.
The following multiplexer types are available at present:
11.6 PC cards
PC cards are installed between the PC and Hicom 100 E for video and data communication.
Install an S
0
bus (master only, no slave) in Hicom 100 E. Moreover, configure appropriate MSNs
for the picture telephone selection.
The PBX <-> PC card connection is set up using the V.24 adapter cable.
For more information, please refer to the appropriate manufacturer specifications.
The following PC cards are available at present:
●
Smart Set
●
I-View
●
Picture Tel
●
Videokit
Multiplexer Connection to Hicom 100 E
DATUS 5810 / 20S Configure S
0
port as CorNet port (code 19 3)
SIMUX 3612 Configure S
0
port as CorNet port (code 19 3)
RAD Kilomux 2000 Configure S
0
port as CorNet port (code 19 3)
