Programming expansion module
A31003-K16-X001-3-7620, 07/99
Hicom 100 E Version 2.1, Service manual
10-77
Programming guide
Example
: the response time for actuator 1 is to be set to 5 seconds – value to be entered is 50.
10.8.1.3 Allocating extensions and actuators
An extension must be allocated in the case of actuators 5 and 8.
The entrance telephone must be allocated in the case of actuator 4.
The other actuator types can be activated from all extensions (no ext. no. assigned) or from one
extension or the members of a call group (ext. or group no. assigned).
Example
: it should be possible for members of call group 883 to activate actuator 1.
Input sequence Meaning Display
A2 5 2
Actuator response time
(select actuator 1–4 with "+" and "–" or
directly with "#")
Actuator no. 1: 255
B
* Change input Actuator no. 1:
C50
Select response time factor Actuator no. 1: 50
D<OK>
Confirm input Actuator no. 1: 50
E
<F8> Return to Start menu System administration
A different response time can be defined by entering another value under point C.
Input sequence Meaning Display
A2 5 3
Ext. assigned for each actuator
(select actuator 1–4 with "+" and "–" or
directly with "#")
Actuator no. 1: –
B
* Change input Actuator no. 1:
C883
Select ext. number Actuator no. 1: 883
D<OK>
Confirm input Actuator no. 1: 883
E
<F8> Return to Start menu System administration
An assigned extension can be deleted by pressing the F3 key under point C.
