Standard extension number plans
Overview of modules
A31003-K16-X001-3-7620
,
07/99
3-6
Hicom 100 E Version 2.1, Service manual
Hicom 118 has four slots for continuing system expansion with line modules and/or extension
modules. A combination of ISDN and analogue trunk connections is possible.
3.3 Standard extension number plans
3.3.1 Standard numbering of the MB modules
System System expansions Function expansions
Hicom 108 1 > slot 1 4
Hicom 112 2 > slots 1 and 3 4
Hicom 118 4 > slots 1 to 4 4
Table 3-3 Possible expansions
Hicom
108
Ext. no. Int. ext.
no.
DDI no. Port
numbering
Type
MB
U
P0/E
11 11 11 1 U
P0/E
MU
P0/E
master
12 12 12 2 U
P0/E
M
17 17 17 1 U
P0/E
S U
P0/E
slave
18 18 18 2 U
P0/E
S
a/b
23 23 23 1 a/b
24 24 24 2 a/b
25 25 25 3 a/b
26 26 26 4 a/b
Table 3-4 Standard numbering, MB 2/4 Hicom 108 (SW 2.0.1)
Hicom
108
Ext. no. Int. ext.
no.
DDI no. Port
numbering
Type
MB
U
P0/E
11 11 11 1 U
P0/E
MU
P0/E
master
12 12 12 2 U
P0/E
M
13 13 13 1 U
P0/E
S U
P0/E
slave
14 14 14 2 U
P0/E
S
a/b
15 15 15 1 a/b
16 16 16 2 a/b
17 17 17 3 a/b
18 18 18 4 a/b
Table 3-5 Standard numbering, MB 2/4 Hicom 108 (as of SW 2.0.1+)
