Networkin
A31003-K16-X001-3-7620, 07/99
Hicom 100 E Version 2.1, Service manual
10-11
Programming guide
10.3.5 Route assignment
When different line types are simultaneously used in the Hicom 100E system (e.g. trunk lines
and PBX lines), each different line type is to be assigned to a separate route.
Automatic line seizure must first be deactivated!
Example
: lines 1 and 2 are to be assigned to route 1 (default status). Line 3 is to be assigned
to route 2.
Input sequence Meaning Display
A 1 6 2 (up to
SW2.0.2)
1 6 12(as of SW2.1)
Assignment of line 1 to route 1
(select line 1–32 with "+" and "–" or
directly with "#")
Line 1: 1
B+
Assignment of line 2 to route 1 Line 2: 1
C+
Assignment of line 3 to route 1 Line 3: 1
D*
Change input Line 3:
E2
Assignment of line 3 to route 2 Line 3: 2
F<OK>
Confirm input Line 3: 2
G
<F8> Return to Start menu System administration
One line can be assigned to one of the four routes by entering the route number 1 to 4 under
point E.
