Programming expansion modules
Programming guide
A31003-K16-X001-3-7620
,
07/99
10-82
Hicom 100 E Version 2.1, Service manual
10.8.2.8 Assigning sensor names
A name which will appear in the optiset display of the destination extension called can be
assigned for each sensor. An optiset (E) memory telephone is necessary for this purpose.
Example
: sensor 1 is to be called "Water".
10.8.3 Programming the fax/DDI module
A connected fax/DDI module which is recognised by the system (see Chap. 5 "Installation" in
the Service Manual) can be programmed to perform the following functions:
1. Fax option: fax recognition function for analogue trunk lines and the autofax function
2. DDI option: pseudo-DTMF DDI for analogue trunk lines
3. Fax/DDI option: combination of fax recognition and pseudo-DTMF DDI
4. Announcement without notification: announcement without notification feature
(
as of SW 2.0.2
)
5. Autofax: additional fax signals from lines that are not assigned to a fax option.
Up to 4 fax/DDI modules can be connected to the system.
The following programming procedures should be performed step by step.
.
Input sequence Meaning Display
A2 6 8
Sensor names
(select sensor 1–4 with "+" and "–" or
directly with "#")
Sensor no.1: –
B
* Change input Sensor no.1:
CWater
Enter name Sensor no. 1: Water
D<OK>
Confirm input Sensor no. 1: Water
E
<F8> Return to Start menu System administration
A sensor name can be deleted with the F3 key under point C.
The
first
step entails defining the planned option type as well as the number of
modules.
