Hicom 100 E Version 2.1, Service manual
10.3.3.2 Connection as slave
In this type of network, at least one TLA 2 or TLA 4 module is required in the Hicom 100E
system. At least one trunk interface is to be connected to an analogue extension interface
(DTMF flash necessary) of the main PBX.
The route in which the lines to the main PBX are located is to be programmed as a "PBX".
Example
: the line to the main PBX is located in route 2
For the input sequence for the route assignment, see Section 10.3.5
Route 2 is programmed as a PBX.
10.3.4 Automatic line seizure (Simplified dialling)
The line is seized automatically when an outgoing external call is set up from an "optiset..."
system telephone. All lines are therefore located in one and the same route.
Automatic line seizure must be deactivated if lines are to be distributed to two or more different
routes. In this case, it is necessary to prefix the number with the appropriate route code in order
to set up an external call.
Input sequence Meaning Display
A 1 6 4 (up to
SW2.0.2)
1 6 14(as of SW2.1)
Line type route 1
(select route 1–4 with "+" and "–" or
directly with "#")
Route 1: trunk
B+
Line type route 2 Route 2: trunk
C*
Change input Route 2:
D1
PBX type Route 2: PBX
D<OK>
Confirm input Route 2: PBX
E<F8>
Return to Start menu System administration
The line type of a route can be reprogrammed as a "trunk" by entering "0" under point D.
Input sequence Meaning Display
A 1 6 1 (up to
SW2.0.2)
1 6 11(as of SW2.1)
Simplified dialling Status: on
B*
Change input Status:
C0
Simplified dialling OFF Status: on
D<OK>
Confirm input Status: on
E<F8>
Return to Start menu System administration
Deactivated automatic line seizure can be reactivated by entering "1" under point C.
