Hicom 112 system overview
System data
A31003-K16-X001-3-7620
,
07/99
2-6
Hicom 100 E Version 2.1, Service manual
2.6 Hicom 112 system overview
Figure 2-3 Hicom 112 structural concept
Slots 1 and 3 for system expansions
:
Freely assignable with line modules (see Table 3-12)
Cover/MDF
PSU1/UPS1
Basic system
Function expansions
Hicom 112
3
1
1... 4
Plug in and
secure (screw)
Plug in
System expansion
System expansion
