Station attributes
Programming guide
A31003-K16-X001-3-7620
,
07/99
10-26
Hicom 100 E Version 2.1, Service manual
10.5.2.3 Programming the receiving extension for the doorbell (up to SW 2.0.1+)
A call can be signalled at an extension or a group of extensions by pressing a de-energized
doorbell connected to the door opener adapter. The number of an extension or a pre-
programmed extension group must be entered as the receiving extension of the doorbell.
Example
: ext.15 should ring when the doorbell is pressed.
10.5.2.4 Programming a receiving extension for the doorbell (as of SW version 2.0.2)
A call can be signalled at an extension or a group of extensions by pressing a de-energized
doorbell connected to the door opener adapter. The number of an extension or a pre-
programmed extension group must be entered as the receiving extension for the doorbell for
each door (1–4).
Example
: ext. 11 should ring when the doorbell on door 1 is pressed, ext. 12 should ring when
the doorbell on door 2 is pressed
Input sequence Meaning Display
A2 3 2
Receiving extension for doorbell Ext. no.: –
B*
Change input Ext. no..
C15
15 is receiving extension for doorbell Ext. no.: 15
D<OK>
Confirm input Ext. no.: 15
E
<F8> Return to Start menu System administration
An activated doorphone destination can be deactivated by pressing the F3 key under point C.
Input sequence Meaning Display
A2 3 2
Receiving extension for door 1
doorbell
(select door 1–4 with "+" and "–" or
directly with "#")
Door 1: –
B+
Change input Door 1:
C11
11 is receiving extension for door 1
doorbell
Door 1: 11
D<OK>
Confirm input Door 1: 11
E+
Scroll to door 2 Door 2: –
F
* Change input Door 2:
G
12 12 is receiving extension for door 2
doorbell
Door 2 12
H
<OK> Confirm input Door 2: 12
J
<F8> Return to Start menu System administration
