Upgrading a system
Initial operation
A31003-K16-X001-3-7620
,
07/99
6-20
Hicom 100 E Version 2.1, Service manual
6.11 Upgrading a system
As of SW version 2.0.2, the software is no longer upgraded by replacing the appropriate
EPROMs, but rather by using a PC tool connected via the system’s V.24 interface on the MB.
The PC is to be connected to the system via the V.24 adapter cable S30122-X5468-X for this
purpose.
Conversion necessary when upgrading with customer batch, see Section 6.12.
Proceed as follows for software upgrading:
1. Copy the file with the new software version to the "Loader" directory on the PC hard disk.
2. Connect the PC to the system (see above).
3. Start the "Loader.exe" PC tool (by double-clicking on the Flash icon).
4. Enter a special password at the programming telephone ext. 11:
5. The message "Remote Admin. Allowed r" appears on the programming ext. 11.
6. Reset the system by disconnecting and then reconnecting the mains plug (after 5
seconds).
7. Select the IC symbol within the Loader program
8. Select the file containing the new SW version and click "OK".
9. The data is loaded to the system. This lasts approx. 10 minutes.
10. The system is then automatically booted. The PC tool can be exited.
11. Once the system has re-booted, perform system Nationalisation( Section 6.3) and reenter
the customer programming.
If an error message appears, abort the load process and start again from point 7 of the upgrade
instructions.
Caution
The S30122-X5468-
X01
cable must
not
be used to upgrade the software.
!
Password for flash
programming.
Enter code for "System
administration".
13290396
*95
