System data
Euroset line 36/Hicom 118-2
A31003-K16-X001-3-7620
,
07/99
12-16
Hicom 100 E Version 2.1, Service manual
Enter the above password to change the extension number plan of the basic box in a two-box
system from 3-digits extension numbers (200-319) to 2-digit extension numbers (11–74).
This ensures that the extension number plan of the basic box and the expansion box is uniform.
The extension numbers in the expansion box remain 3-digit numbers and must be changed with
the ASSISTANT L PC tool.
Contact Port X1
UP0/E
Port X2
UP0/E
Port X3
a/b
Port X4
1a1 - port 1 a 1 - port 1 GND
2b1 - port 1 b 1 - port 1 not assigned
3a2 - port 2 a 2 - port 2 not assigned
4b2 - port 2 b 2 - port 2 EXMCL
5 a3 - port 3 a 3 - port 3 EXMDIR
6 b3 - port 3 b 3 - port 3 HRES
7 a4 - port 4 a 4 - port 4 EXMD
8 b4 - port 4 b 4 - port 4 EXMDET
9 a5 - port 5 +5V
10 b5 - port 5 not assigned
11 a6 - port 6
12 b6 - port 6
Table 12-9 Contact assignment of the MB interfaces 6/4 Hicom 118-2’
Password for two-box system for chang-
ing the extension number plan
Enter code for "System ad-
ministration".
16122320
*95
