PLC device configuration
6.1 Configuring the operation of the PLC system
S7-200 SMART
136 System Manual, 09/2015, A5E03822230-AC
Coefficient
Depending upon the RTD resistor that you select, you can configure the following RTD
temperature coefficients for the channel:
RTD resistors
RTD temperature coefficients
• 48 ohms
• 150 ohms
• 300 ohms
• 600 ohms
• 3000 ohms
Note: For these RTD resistors, you cannot con-
figure temperature coefficients or temperature
scales.
• Pt 10
• Pt 50
• Pt 0.00385055
• Pt 0.003910
• Pt 100
• Pt 500
• Pt 0.00385055
• Pt 0.003916
• Pt 0.003902
• Pt 0.003920
• Pt 0.003910
• Pt 200
• Pt 1000
• Pt 0.00385055
• Pt 0.003916
• Pt 0.003902
• Pt 0.003920
• Ni 100 • Ni 0.006170
• Ni 0.006180
• Ni 0.006720
• Ni 120
• Ni 200
• Ni 500
• Ni 1000
• Ni 0.006180
• Ni 0.006720
• Cu 10 • Cu 0.00426
• Cu 0.00428
• Cu 0.00427
• Cu 50
• Cu 100
• Cu 0.00426
• Cu 0.00428
• LG-Ni 1000 • LG-Ni 0.005000

Siemens Simatic S7 Series Specifications

General

CPU	Varies by model (e.g., S7-300, S7-400, S7-1200, S7-1500)
Communication Interfaces	PROFIBUS, PROFINET, Ethernet, MPI
Programming	TIA Portal, STEP 7
Programming Languages	LAD, FBD, STL, SCL, GRAPH
I/O Modules	Digital, Analog, Specialty modules available
Operating Temperature	0°C to 60°C (standard models)
Mounting	DIN rail mounting
Operating Voltage	24V DC or 120/230V AC (varies by model)
Protection Class	IP20 (standard models)
Memory	Varies depending on the S7 model. Includes work memory (RAM) for program execution, load memory (EEPROM or Flash) for program storage, and system memory for operating system functions. Memory sizes range from kilobytes to megabytes.
