Ordering information
F.3 Programming software
S7-200 SMART
706 System Manual, 09/2015, A5E03822230-AC
Expansion modules and signal boards
Article number
SB Digital 2 x Inputs / Digital 2 x Outputs (SB DT04)
6ES7 288-5DT04-0AA0
SB Analog 1 x Output (SB AQ01) 6ES7 288-5AQ01-0AA0
SB Analog 1 x Input (SB AE01)
6ES7 288-5AE01-0AA0
SB RS485/RS232 (SB CM01) 6ES7 288-5CM01-0AA0
SB Battery (SB BA01)
6ES7 288-5BA01-0AA0
F.3
Programming software
Programming software
Article number
STEP 7-Micro/WIN SMART Individual License (CD-ROM)
6ES7 288-8SW01-0AA0
Drives V90 (PC tools) software Can be downloaded from
the Siemens Services and
Support website
F.4
Communication
Communications cards
Article number
CP 5411: Short AT ISA
6GK 1 541-1AA00
CP 5512: PCMCIA Type II
6GK 1 551-2AA00
CP 5611: PCI card (version 3.0 or greater)
6GK 1 561-1AA00
F.5
Spare parts and other hardware
Cables, network connectors, repeaters, and end retainers
Article number
MPI Cable
6ES7901-0BF00-0AA0
PROFIBUS Network Cable
6XV1 830-0AH10
Network Bus Connector with Programming Port Connector, Vertical Cable Outlet
6ES7972-0BB11-0XA0
Network Bus Connector (no programming port connector), Vertical Cable Outlet
6ES7972-0BA11-0XA0
RS485 Bus Connector with 35° Cable Outlet (no programming port connector)
6ES7972-0BA40-0XA0
RS485 Bus Connector with 35° Cable Outlet (with programming port connector)
6ES7972-0BB40-0XA0
RS485 IP 20 Repeater, Isolated
6ES7972-0AA00-0XA0
TD/CPU Connecting Cable
6ES7901-3EB10-0XA0
End Retainer Thermoplast, 10 MM
8WA 1808
End Retainer, Steel
8WA 1805

Siemens Simatic S7 Series Specifications

General

CPU	Varies by model (e.g., S7-300, S7-400, S7-1200, S7-1500)
Communication Interfaces	PROFIBUS, PROFINET, Ethernet, MPI
Programming	TIA Portal, STEP 7
Programming Languages	LAD, FBD, STL, SCL, GRAPH
I/O Modules	Digital, Analog, Specialty modules available
Operating Temperature	0°C to 60°C (standard models)
Mounting	DIN rail mounting
Operating Voltage	24V DC or 120/230V AC (varies by model)
Protection Class	IP20 (standard models)
Memory	Varies depending on the S7 model. Includes work memory (RAM) for program execution, load memory (EEPROM or Flash) for program storage, and system memory for operating system functions. Memory sizes range from kilobytes to megabytes.
